IEC Cable Sizing Calculator
Free online IEC 60364‑5‑52 cable sizing calculator for electrical engineers. Instantly size LV/HV cables, check voltage drop, apply correction factors, and get a recommended configuration. Supports copper & aluminium, all insulation types, and installation methods.
Introduction
Choosing the correct cable size is critical for safety and performance. This IEC 60364‑5‑52 cable sizing calculator helps you determine the minimum conductor cross‑section, evaluate voltage drop, and select the best cable configuration, all in compliance with the international standard. Whether you’re a professional electrical engineer, an MEP consultant, or an electrical design student, this tool streamlines your design workflow.
Key Features
- Fully compliant with IEC 60364‑5‑52 (Tables B.52.2 to B.52.13)
- Flexible load input: Amperes, kW, kVA, MW, MVA with motor efficiency and diversity/growth factors
- All insulation & conductor types: PVC (70°C), XLPE (90°C), Copper & Aluminium
- Single‑core and multi‑core cables with trefoil/flat/spaced arrangements
- All installation methods: A1, B1, C, E, F, G, D1, D2 (underground ducts/direct buried)
- Correction factors: ambient/ground temperature, grouping, soil thermal resistivity, harmonic derating
- Voltage drop calculation with separate resistive & reactive components
- Automatic or manual parallel runs with recommended configuration
- Print‑friendly report with input summary and results
- Mobile‑friendly and ad‑free
How to Use the Calculator
- Select Load Input – enter current directly or convert from power.
- Set System Parameters (voltage, power factor, circuit length, supply type).
- Choose Cable Specification (insulation, conductor, core arrangement).
- Pick the Installation Method and define Correction Factors.
- Click Calculate Cable Size.
- Review the recommended configuration and voltage drop breakdown.
- Use Print (CTRL+P)/ Save PDF for your records.
Why Trust This Calculator?
- Based on publicly available IEC 60364-5-52 tables and correction factor data.
- Developed by TheTechSyllabus.com, a trusted resource for electrical engineering education.
- Used by thousands of engineers worldwide for quick and reliable cable sizing.
FAQ
Q: What is IEC 60364‑5‑52?
A: It is the international standard for the selection and erection of electrical equipment, specifically for current‑carrying capacities of cables. This calculator follows the tabulated values and correction factors from that standard.
Q: Can I calculate aluminium cable sizes?
A: Yes, the tool supports both copper and aluminium conductors, with a minimum size of 16 mm² for aluminium as per the standard.
Q: Does this calculator consider voltage drop?
A: Absolutely. The tool calculates total voltage drop as well as the breakdown of resistive and reactive drops. It compares the result against the limits for public or private supplies.
Q: Is the tool free to use?
A: Yes, it’s completely free with no registration required.
